Temporary Fixation

TOGE TSM BC ST

Concrete screw for construction site safety and temporary fixation

Our concrete screw TOGE TSM is suitable for a wide range of applications in the field of construction site safety or temporary fastening: Whether for fastening guardrails, scaffolding or formwork props. With special approval for use in fresh concrete and completely dismountable and thus reusable.


TOGE TSM – At a Glance


Fast and safe installation

The optimized thread enables a fast and safe installation process.

High loads

High load bearing capacity in cracked and non-cracked concrete.

Special approval

Anchoring of site equipment in fresh concrete.

Temporary fastening

For temporary fastening also in outdoor areas.

Demountable

Residual disassembly and therefore reusable.

Headshapes and Materials


01 | TSM BC ST

Concrete screw with collar – Steel, zinc plated

01 | TSM BC ST

Concrete screw with collar – Steel, zinc plated


02 | TSM HP Concrete Screw

Hexagonal head with pressed on washer- Steel, zinc plated

02 | TSM HP Concrete Screw

Hexagonal head with pressed on washer- Steel, zinc plated


03 | TSM HP Concrete Screw ZFC

Hexagonal head with pressed on washer- Steel, zinc flake-coated

03 | TSM HP Concrete Screw ZFC

Hexagonal head with pressed on washer- Steel, zinc flake-coated




Which product is right for you?

Do you need support?
We will be happy to help!

Call us: +49 911 659 68-10


Application Examples




Fastening of guardrails, scaffolding or formwork props



Approval | Installation Instructions | Technical Information


Approval


Base Materials

Application in cracked and non-cracked concrete
of strength classes from C20/25 to C50/60.


This is how simple the installation works:

  1. Create borehole.
  2. Thoroughly clean borehole.
  3. Screw in concrete screw TOGE TSM High Performance.
  4. The screw head must rest completely on the attachment.

Downloads




Product
Information



Technical
Data



General design type approval
Z-21.8-2115 for temporary fastening.
