TOGE TSM Multiground
Female threaded screw for various substrates
TOGE TSM MULTIGROUND
ONE Screw for various substrates
Use only ONE screw in different substrates? This is now possible – with our new TOGE TSM Multiground!
The practical internally threaded screw for different substrates offers you a wide range of application options in interior construction, e.g. fastening ceiling suspensions, cable ducts, piping, consoles, cladding and much more. The TOGE TSM Multiground has an ETA-23/0542 approval in concrete. It is also suitable for masonry, aerated concrete and wood substrates. The installation is carried out easily with a tangential screwdriver. This makes it much easier to work overhead.
You can see how easy and fast the installation works in our video.
The practical internally threaded screw for different substrates offers you a wide range of application options in interior construction, e.g. fastening ceiling suspensions, cable ducts, piping, consoles, cladding and much more. The TOGE TSM Multiground has an ETA-23/0542 approval in concrete. It is also suitable for masonry, aerated concrete and wood substrates. The installation is carried out easily with a tangential screwdriver. This makes it much easier to work overhead.
You can see how easy and fast the installation works in our video.
TOGE TSM MULTIGROUND – At a glance
Easy Installation
Easy, fast and safe installation with a impact screwdriver. This makes overhead work in particular much easier.
High load values
The special thread geometry ensures a secure hold and high loads in concrete.
Flush with surface
The flush surface installation results in a clean installation appearance without any interfering elements.
Small edge distances
Small edge distances and spacing allow particularly close-edge and closely spaced installation.
Versatile
The practical internal thread enables use for a wide range of applications.
Demountable
If required, the TOGE TSM Multiground can be quickly and easily dismounted.
Headshapes and Materials
Which product is right for you?
Do you need support?
We will be happy to help!
Call us: +49 911 659 68-43
Application Examples
Fastening of cable ducts
Fastening of piping
Detail: TSM Multiground with threaded rod and pipe clamp
Fastening of ceiling suspensions of any kind
Approval | Installation Instructions | Technical Information
Approval
Base Material
Approved for concrete strenght classes from C20/25 to C50/60.
Cracked and non-cracked concrete
Suitable for masonry, aerated concrete and wood.
This is how simple the installation works:
- Create drill hole with hammerdrill or hollow drill bit.
- Thoroughly clean drill hole.
- Screw in TOGE TSM Multiground with impact screwdriver or wrench.
- Screw must be screwed in flush with the surface of the concrete. The attachment part is fastened with a standard metric screw or threaded rod.
