Concrete Screw TOGE TSM High Performance

Concrete Screw

TOGE TSM High Performance

Our all-rounder concrete screw – even for heavy loads

  • Large variety
  • Adjustable & Demountable
  • Particulary near the edge
  • Easy and fast installation
  • High load level
  • Combinable system
Large variety
Seven different head shapes and up to three different embedment depths for variable load absorption: always perfectly matched to your individual requirements.
Adjustable & Demountable
If required, the TOGE TSM High Performance can be adjusted up to twice during assembly. After assembly, it can be disassembled again at any time.
Particulary near the edge
Small edge distances and spacing allow very closed-edge and closely spaced installation.
Easy and fast installation
The optimized thread enables a fast and easy installation process.
High load level
The special thread geometry ensures extreme hold and high loads in concrete – whether tensile or shear loads.
Combinable system
In combination with our composite mortar, the TSM HP has an even higher load level – and can be loaded immediately. Tested impermeability, even to critical substances, enables use even under WHG requirements (only for TSM LT A4).
ETA 15/0514
ETA 16/0123
ETA 23/0099
ETA 21/0425
Our TOGE TSM High Performance is our most versatile concrete screw. Approved for concrete strength classes from C20/25 to C50/60 – in both cracked and non-cracked concrete – it is suitable for a wide range of applications: from fastening piping, ceiling hangers, ventilation ducts, railings or handrails to heavy-duty use for fastening heavy-duty shelving. With a wide variety of head shapes and up to three different anchoring depths, the right screw can be found for every requirement.

PRODUCT VIDEO
DOWNLOADS

Headshapes and Materials

01 | TSM SW

Hexagonal head – Steel, zinc plated

01 | TSM SW

Hexagonal head – Steel, zinc plated

02 | TSM SW ZFC

Hexagonal head – Steel, zinc flake-coated

02 | TSM SW ZFC

Hexagonal head – Steel, zinc flake-coated

03 | TSM SW LT A4

Hexagonal head – stainless steel A4

03 | TSM SW LT A4

Hexagonal head – stainless steel A4

04 | TSM C VZ

Countersunk head with multipoint drive – Steel, zinc plated

04 | TSM C VZ

Countersunk head with multipoint drive – Steel, zinc plated

05 | TSM C VZ LT A4

Countersunk head with multipoint drive – stainless steel A4

05 | TSM C VZ LT A4

Countersunk head with multipoint drive – stainless steel A4

06 | TSM LP VZ

Large panhead with multipoint drive – Steel, zinc plated

06 | TSM LP VZ

Large panhead with multipoint drive – Steel, zinc plated

07 | TSM P VZ

Panhead with multipoint drive – Steel, zinc plated

07 | TSM P VZ

Panhead with multipoint drive – Steel, zinc plated

08 | TSM P VZ LT A4

Panhead with multipoint drive – stainless steel A4

08 | TSM P VZ LT A4

Panhead with multipoint drive – stainless steel A4

09 | TSM M8-16 SW

Hexagonal head with metric connection thread M8 – Steel, zinc plated

09 | TSM M8-16 SW

Hexagonal head with metric connection thread M8 – Steel, zinc plated

09 | TSM M10-20 SW

Hexagonal head with metric connection thread M10 – Steel, zinc plated

09 | TSM M10-20 SW

Hexagonal head with metric connection thread M10 – Steel, zinc plated

10 | TSM IM M8/10

Metric female thread M8/10 – Steel, zinc plated

10 | TSM IM M8/10

Metric female thread M8/10 – Steel, zinc plated

11 | TSM IM M8/10 LT A4

Metric female thread M8/10 – stainless steel A4

11 | TSM IM M8/10 LT A4

Metric female thread M8/10 – stainless steel A4

12 | TSM AG SW

Metric connection thread – Steel, zinc plated

12 | TSM AG SW

Metric connection thread – Steel, zinc plated

13 | TSM AG A4

Metric connection thread – stainless steel A4

13 | TSM AG A4

Metric connection thread – stainless steel A4

Which product is right for you?

Do you need support?
We will be happy to help!

Call us: +49 911 659 68-54

Get in touch

Approval | Installation Instructions | Technical Information

Approvals

European technical assessment ETA-15/0514, single fastening.
European technical assessment ETA-16/0123, multiple fastening.
European technical assessment ETA-23/0099, single fastening in masonry.
European technical assessment ETA-21/0425, TSM LT A4.
General design approval Z-21.8-2115 for temporary fastening.
General design approval Z-21.1-2074 adhesive concrete screw.
UKTA 22/6551, single fastening.
UKTA 22/6496, multiple fastening.

ETA-15/0514

ETA-16/0123

ETA-23/0099

ETA-21/0425

Base Materials

Approved for concrete strength classes from C20/25 to C50/60.
Cracked and non-cracked concrete.
Approved for masonry (see technical data for types).
Prestressed hollow core slabs (size 6).
Suitable for natural stone with dense structure.

This is how simple the installation works:

  1. Create borehole.
  2. Thoroughly clean borehole.
  3. Screw in concrete screw TOGE TSM High Performance.
  4. The screw head must rest completely on the attachment.

Illustration shows installation in concrete. For installation instructions in masonry please see technical data.

Application Examples

Fastening piping

Fastening ventilation ducts

Fastening of racks in high-bay warehouses

Fastening railings

Downloads

Product
Information

Technical
Data

European technical assessment
ETA-15/0514 single fastening

European technical assessment
ETA-16/0123 multiple fastening

European technical assessment
ETA-23/0099, single fastening in masonry

European technical assessment
ETA-21/0425, TSM LT A4

General design type approval
Z-21.8-2115

General design type approval
Z-21.1-2074

Declaration of performance
TSM 5-6

Declaration of performance
TSM 6-14

Declaration of performance
TSM LT A4

Certificate of constancy of
performance TSM HP
ETA-15/0514

Certificate of constancy of
performance TSM HP
ETA-16/0123

Certificate of constancy
of performance TSM LT A4
ETA-21/0425

Certificate of constancy
of performance TSM HP
Z-21.1-2074

Report
hollow core slabs

UKTA 22/6551
single fixings

UKTA 22/6469
multiple fixings

UKCA for 22/6551

FPC for 22/6469
